9-19, 9-26 kaitech high efficiency industrial centrifugal blower, exhaust fan price
Functions
9-19,9-26 series high pressure centrifugal ventilator fan
9-19,9-26 series high pressure centrifugal ventilator fan usually apply to forge furnace or for the purpose of high pressure forced ventilation, also used to transport material, air and non-corrosion, non-spontaneous and non-sticky material gas. The temperature of the medium is no more than 50ºC normally(The maximum temperature does not exceed 80ºC), dust and hard particle contained is not more than 150mg/m³.
We can design,manufacture and integral install the 9-19,9-26 series ventilator with vibration attenuation pedestal type.
We can design ,manufacture anti-explosion 9-19,9-26 series ventilator with
1. Vibration reduction stage posture fan
2. Double suction fan
3. High temperature 9-19,9-26 series fan
4. Corrosion resistance 9-19,9-26 series fan
Spare parts in details:
Our company has independent R & D team; all products are using CAD / CAM computer-aided design; product appearance adopts three-dimensional solid design; key components are analyzed by numerical simulation, rotatable components pass dynamic balance test.
Rotech factory:
Shandong Rotech Blower Co.,Ltd, a professional manufacturer of fan, is the wholly-owned subsidiary of Shandong Kaitai Group Co.,Ltd, which integrates technical research, development and production.
Shandong Kaitai Group Co.,Ltd,which occupies 60,000 square meters. With 17 sales branches across the country and 10 overseas branches, the company has established a multinational sales and service network.
Certificate:
With advanced technology and production equipment,our company is awarded as the new high-tech enterprise of Shandong Province and occupational health and safety management system certification and CE certification to European markets.
- Size: 5CBM
- Place of Origin: Shandong
- Brand Name: Rotech
- Model Number: 9-19
- Weight: 1300.000 kg
Parameters
Product No | Rotate speed r/min | Capacity m3/h | Total pressure Pa | Motor power kW |
4A | 2900 | 2198-3215 | 3407-3852 | 5.5 |
4.5A | 2900 | 3130-4792 | 4256-4910 | 7.5-11 |
5A | 2900 | 4293-6762 | 5180-6035 | 15-18.5 |
5.6A | 2900 | 6032-9500 | 6527-7610 | 22-30 |
6.3A | 2900 | 8588-13525 | 8310-9698 | 45-55 |
7.1D | 2900 | 12292-19360 | 10635-12427 | 75-110 |
8D | 2900 | 17584-24696 | 13634-15955 | 132-200 |
1450 | 8792-13848 | 3294-3834 | 18.5-30 | |
9D | 1450 | 12518-19717 | 4181-4869 | 30-45 |
10D | 1450 | 17172-30052 | 5065-6143 | 55-75 |
11.2D | 1450 | 24126-42221 | 6382-7747 | 110-132 |
960 | 15973-27953 | 2763-3346 | 30-37 | |
12.5D | 1450 | 33540-58600 | 7993-9713 | 160-250 |
960 | 22206-38860 | 3450-4179 | 45-75 | |
14D | 1450 | 47121-82463 | 10095-12285 | 250-410 |
960 | 31197-54596 | 4341-5262 | 75-110 | |
16D | 1450 | 70339-123090 | 13324-16250 | 500-850 |
960 | 46569-81496 | 5696-6911 | 185-220 |
